Customized cold forming molds and dies are specialized tools designed and manufactured according to specific customer drawings or technical specifications. These tools are used in cold heading machines (also known as cold formers or header machines) to shape raw wire or rod materials into complex, non-standard geometries without heating the material.
库存： 0
Inquire
Add to Basket
| Mode | Unit | K.505 | K-506 | KD-506 | KD-508 | KD-510 | KD-513 | KD-516 | KD-520 | KD525 |
| Forging station | No. | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| Forging force | Kgf | 46000 | 55000 | 55000 | 80500 | 125000 | 172000 | 295000 | 435000 | 650000 |
| Max.cut-off dia | mm | 06 | 08 | 08 | 010 | 012 | 016 | 023 | 025 | 032 |
| Max.cut-of length | mm | 80 | 95 | 100 | 140 | 165 | 220 | 240 | 260 | 280 |
| Production speed | pcs/min | 240 | 200 | 220 | 200 | 200 | 120 | 95 | 80 | 65 |
| Master die ejection Blow | mm | 70 | 70 | 90 | 130 | 145 | 200 | 220 | 240 | 255 |
| Punch die ejection Blow | mm | 30 | 30 | 30 | 40 | 40 | 60 | 60 | 65 | 70 |
| Main sliding table Blow | mm | 120 | 120 | 130 | 160 | 195 | 270 | 285 | 355 | 370 |
| Overall dims.Of mian die | mm | 050*90 | 050*100 | 050*100 | 060*130 | 075*130 | 080*190 | 0108*200 | 0125*240 | 0140*250 |
| Overall dims.Of punch die | mm | 038*85 | 038*85 | 040*100 | 045*115 | 053*125 | 070*130 | 075*185 | 090*215 | 0120*270 |
| Overall dims..Of cut of die | mm | 028*35 | 028*35 | 028*45 | 040*60 | 045*60 | 070*69 | 075*100 | 075*120 | 080*130 |
| Die pitch | mm | 55 | 55 | 60 | 80 | 94 | 110 | 129 | 140 | 160 |
| Applicable bolt dia | mm | 2-5 | 3-6 | 3-6 | 3-6 | 6-10 | 8-16 | 10-22 | 12-30 | 12-31 |
| Shank lenght of blank | mm | 10-65 | 10-85 | 10-85 | 10-115 | 10-115 | 20-180 | 20-200 | 20-220 | 20-221 |
| Main engine motor | KW | 18.5 | 22 | 22 | 30 | 37 | 55 | 75 | 90 | 115 |
| Machine weight | mm | 7700 | 9900 | 9900 | 19500 | 25300 | 46000 | 66500 | 97200 | 164000 |
